cheap price mini Single Fluid high pressure hydraulic concrete Piston Grouting Pump for sale
Introduction:
Prestressed grouting machine,which is also called piston pump, it can convey mud, yellow mud, sodium silicate, oil water and other media, and it also can  convey medium alone. It can be widely used in tunnels, coal mining working surface grouting water plugging, wall rock and concrete grouting, plugging water tunnel cracks, crushing of rock mass, evacuate the reinforcement of the rock reinforcement, anchoring grouting, backfill grouting and prevent the surface subsidence, landslides, and correct buildings deflection of grouting, etc
Principle:
1. The belt and a pair of gear motor rotary motion to the crankshaft, then via connecting rod, cross-head, piston reciprocating motion, gear box is closed, splash lubrication by using the moving parts.
2. mortar by suction valve through a pump cylinder pressure to discharge air, in the air chamber is equipped with leakage of slurry valve and pressure safety device.
3.  piston pump adopts the electric automatic control safety device.
4.  when the air chamber pressure exceed the rated working pressure,it cut off the main mainstream circuit via controlling circuit, stopping the machine automatically  running.
Features:Â
compact structure, reliable operation, low failure rate. Cleaning and maintenance convenience and high pumping pressure, etc.
| model | HIB-3 | HJB-6 |
| Motor capacity | 3kw | 4kw |
| Pump delivery | 3m³/h | 6m³/h |
| Maximum pressure | 1.5mpa | 3mpa |
| cylinder transfer pipe quantity | Single cylinder | Â Double cylinder |
| Motor speed | 1440r/min | 1440r/min |
| grouting pipe | 32/38mm | 32/38mm |
| Head of delivery | Horizontal 20-50m, vertical<=20m | Horizontal 20-50m, vertical<=20m |
| Â boundary dimension | 1250*430*850 | 1250*430*850 |
| weight | 250kg | 320kg |
Packaging &Â Shipping
1.Packaging:1)Wrapped by protective film;
2)Packed by standard import &Â export wooden cases or carton boxes.
2.Shipping:By logistics;By automobile;By train;By shipping;By air etc.
Payment Terms
We accept L/C, T/T, Western Union, Money Gram, Paypal, Alibaba Escrow etc.
Â
Frequently Asked Questions
1.Q:Are you trading company or manufacturer?
A:We are original equipment manufacturer.
2.Q:How long is your delivery time?
A:It is according to the model and quantity.
Generally it is 3-5 days if the machines are in stock.
It will be 15-30 days if you want to customize the machines.
3.Q:Do you provide samples?Is it free or extra?
A:Yes, we could offer you the sample machine.
But it's not free.You need to pay for the sample and the cost of freight.
4.Q:What is your terms of payment?
A:We accept T/T, Western Union, Money Gram, Paypal, Alibaba Escrow etc.
Payment<=USD 5000, 100% in advance.
Payment>=USD 5000, 30% T/T in advance, balance before shipment.
About Us
Henan Yugong Machinery Co., Ltd.Is a large machinery manufacturing enterprise which focuses on research and development, production and sales of mining, tunnel construction, road and bridge construction equipments and so on.
We believes that good quality can give us survival, thus we only provide you top products.All the products with high quality meet international standards and are highly estimated by all clients at home and abroad.
All the staff in our company are professionally trained, so we can recommend you the most appropriate equipment.Every machine will be strictly examined before delivery.
Any question about the machine will be replied within 24 hours.Welcome you to be our new client!
Contact us
Please feel free to contact us at any time if there are any problems!
Vanessa Peng
mob: 0086 138 3817 9662
Â
Â
